BOX One X6 TI tapered 20mm Pro Carbon Fork

All Box One forks are designed and built using their Oversized technology. These forks are the most important component in the quest for bike control. They have moved carbon from low-stress areas to high-load areas. These muscular shoulders are not just for aesthetics, they are essential for achieving superior steering stiffness. When combined with Box’s other Oversized components, you will benefit from increased responsiveness and reduced latency.

Key differences: This fork model features the industry-leading Oversized technology, with a 1-1/8” to 1.5” TITANIUM steerer tube for unmatched strength and precision. Designed with increased tire clearance and wider hips, it offers improved stiffness and performance. The inclusion of robust cold-forged 20mm thru-axle dropouts ensures maximum durability and stability.

FEATURES:

• Vacuum-molded high modulus unidirectional carbon fiber arms
• Extruded and CNC-machined TITANIUM 6Al-4V head tube
• Cold-forged 6061-T6 aluminum and dropouts
• Legs: Vacuum-molded
• Pipe: Extruded and CNC-machined
• Matte Black finish with Prizm decals
• Riser: 20"
• Head tube: 1-1/8" to 1.5"
• Offset: 32mm
• Dropouts: 20mm
• Weight: 615g
• Rider weight limit: 115kg with limitations according to category 2 of EN 16054:2012

COMPATIBILITY:

• For 20" frames with tapered integrated head tube Top 1-1/8'' - Bottom 1.5''
• For 20" wheels with 20mm axle
